PyroButton softwares for Self-powered temperature monitoring system
|
PyroButton-Standard software - PyroButton-Standard includes all of the capabilities of PyroButton-Basic plus a signal smoothing utility and uncertainty of measurement modeling and calculation. PyroButton-Standard is recommended where rigorous metrology is required. PyroButton-Basic is suitable for the operation temperature/humidity data-loggers.
|
Key Features
- Automatic correction of temperature data (based on actual calibrated values) for accuracy (±0.1°C)
- Direct interface to calibration program
- Wizard navigation for easy-learning
- Supports multiple temperature-logger programming & download
- Includes signal smoothing utility
- Includes uncertainty of measurement modeling and calculation
- Battery life-expectancy analysis
- Battery use modeling & optimization
- Integrated Warning/Action levels
- Password protection
- 21 CFR Part 11 compliant
- Control charts with 2-levels of limits
- Histogram of temperature distribution
- Flexible reporting capability
- Excel compatible conversion of data
- XML format support
- Compatible operating systems: Win98, ME, NT, 2000, XP
- IQ-OQ-PQ verification protocol is available
- 21 CFR Part 11 verification protocol is available
|
|
System Requirements
- Pentium 200 MHz CPU
- 64 MB RAM
- 24x CD drive
- 800x600 display resolution, high color (1024x768 recommended)
- Free serial, parallel, or USB port
- Mouse
- 50 MB free hard disk space
- Windows 98, ME, NT 4.0, 2000 or XP operating system
|
|
| 100-PBE-007-002E |
PyroButton-Standard 2.0 software
Capable of both temperature & humidity measurements; compatible with all PyroButtons. Built-in automatic correction of measurement based on
5-point calibration curve. Signal processing program module for optimization of signal smoothing for the reduction of inherent noise of
humidity measurements, improves accuracy, and reproducibility. Built-in uncertainty of measurement calculation. 21 CFR Part 11 compliant,
if used in a closed document environment.
1 workstation license
|
780
/license |
 |
| 100-PBE-007-006 |
IQ-OQ-PQ verification protocol for PyroButton-Standard software |
850
/each |
|
| 100-PBE-007-007 |
21 CFR Part 11 verification protocol for PyroButton-Standard software |
850
/each |
|
|
|
PyroButton-SQL software - PyroButton-SQL sets new standard for the management of sensors/data-loggers, the analysis of the measured data, integration of intelligent modules for validation and verification sterility processes, container/closure moisture permeability, and enterprise wide monitoring of warehouses and transportation system with SMS Self-powered messaging & communication support for e-mail. PyroButton-SQL can be integrated with PyroCAD modeling & simulation software for the determination of Critical Control Point mapping and optimal monitoring for reduced risk & high ROI.
|
Key Features
- PB-SQL includes all of the functionalities of PyroButton-Standard plus:
- Efficient MS SQL database engine for managing a lot of measurement data
- EQUAL Models for:
- Temperature statistical map
- Permeability analysis
- Complete audit trail of who, what, and when
- Sterilization validation (coming)
- Sterilization challenge tests (coming)
- PQ for calibration & calibration verification (coming)
- Clean room validation (coming)
- Validation & challenge studies of temperature & temperature/humidity regulated equipment
- Ad hoc queries
- Batch programming of the data-loggers - programming dozens or even hundreds of loggers with a single mouse click
- Batch data-download - read the measurement data from multiple loggers
- SOP relationships of the measurements (events)
- Multiple view of data sets - display and compare measurements of different data loggers
- Event connected measurement
- Load connected measurements
|
|
System Requirements
- Pentium IV 2 GHz or higher
- 512 MB RAM (1 GB recommended)
- CD drive for installation
- Mouse
- 800x600 display resolution, 256 color (1024x768 resolution with High Color is recommended)
- 2 GB free hard disk space
- Windows 2000 or XP or higher operating system
|
|
| 100-PBE-007-020E |
PyroButton-SQL/Basics v3.8 software with 21 CFR Part 11 compliance
Includes MSDE & SPC. Built-in automatic correction of measurement based on the calibration curve. Signal processing program module for
optimization of signal smoothing for the reduction of inherent noise of humidity measurements, which improve accuracy, and reproducibility.
Built-in uncertainty of measurement calculation.
Optional: IQ-OQ-PQ & 21 CFR Part 11 Verification Protocols
1 workstation license
|
3,670
/each |
|
| 100-PBE-007-016 |
IQ-OQ-PQ verification protocol for PyroButton-SQL/Basic software |
1,250
/each |
|
| 100-PBE-007-017 |
21 CFR Part 11 verification protocol for PyroButton-SQL/Basic software |
1,250
/each |
|
|
|
| 100-PBE-007-021E |
PyroButton-SQL/PRO v3.16 software with 21 CFR Part 11 compliance
Includes 2005 MS SQL Express with SPC (includes: Sterilization, Clean Room, Process, Facilities, & Container/Closure application modules;
provides heat & moisture distribution map, loading effects, container/closure evaluation, PQ, and much more); Built-in automatic correction of
measurement based on the calibration curve. Signal processing program module for optimization of signal smoothing for the reduction of inherent
noise of humidity measurements, which improve accuracy, and reproducibility. Built-in uncertainty of measurement calculation. 21 CFR Part 11
compliant 1 workstation license IQ-OQ-PQ verification protocol 21 CFR Part 11 verification protocol are included.
1 workstation license
|
7,975
/license |
|
|
|
